The FEUR FU-AUL16-AMP Audio Link is a 16-channel powered audio mixer with a built-in Class D amplifier rated at 350W x 2 RMS, 12 mono combo inputs, 2 stereo channels, 2 balanced group outputs, a 199-effect DSP processor, Bluetooth and MP3 playback and +48V phantom power switched individually on every channel. It drives passive speakers directly, which takes two amplifier racks and a pile of cabling out of a mobile rig.
The same 16-channel surface with a Class D amplifier already inside it.
A powered mixer earns its place on a cart. One box goes in the vehicle instead of a mixer, an amplifier and the interconnect between them, and setup drops to speaker cable and input lines. The Class D amplifier section is rated at 350 watts RMS per side into passive cabinets, which covers a banquet hall, a school gym, a church fellowship room or an outdoor event of moderate size. Note that FEUR markets this amplifier as 1400 W Class D in its own documentation while the dealer specification reads 350W x 2 RMS. Call us at 844-687-4208 before you match it to specific cabinets and we will confirm the figure with the factory.
The DSP section carries 199 effects, 100 factory presets plus 100 you can edit and store. Reverbs, delays and the modulation set are all on board, which keeps a rack unit off the cart for most small venue work.
Every channel gets its own switchable +48V phantom power. Most boards in this class put phantom on one global switch, so powering a single condenser powers everything on the surface. Per-channel switching means a condenser and a ribbon can sit side by side and you never have to think about it. Connectivity covers Bluetooth and MP3 playback for walk-in music, and a built-in sound card interface for recording the room straight to a computer.
At a Glance
| Product Type | Analog Audio Mixer with DSP |
| Mono Inputs | 12 channels |
| Stereo Inputs | 2 channels |
| DSP Effects | 199 effects, 100 preset and 100 editable |
| Channel EQ | HF, MF with sweep, LF |
| Auxiliary Outputs | 3 AUX balanced XLR plus 1 AUX/FX, AUX 1-2 pre or post fader selectable |
| Group Outputs | 2 balanced group outputs |
| Phantom Power | +48V, individually switched per channel |
What Inputs Does This Mixer Have?
12 channels of mono input with combo jacks and inserts, plus 2 stereo channels. Every mono channel has its own switchable +48V phantom power and a 4-band EQ with a sweepable mid.
What Outputs Does It Have?
3 balanced XLR auxiliary sends plus a dedicated AUX/FX send, 2 balanced group outputs and the main outputs. Aux sends are what you use for stage monitors, so count them against how many separate monitor mixes you need.
Who Is This Mixer For?
Houses of worship, schools, bands running their own sound, mobile DJs, small clubs, conference rooms and installed systems in restaurants and bars. It suits anyone who needs real channel count and onboard effects without moving to a digital console and a learning curve.
What Comes in the Box?
The powered mixing console, a 1.5 m USB cable for sound card recording, a PC interface connect cable, an IEC power cable and the user manual. Call 844-687-4208 to confirm speaker impedance and cabling for your cabinets before you order.
Can I Record from It?
Yes. A USB Type-B sound card interface connects the mixer straight to a computer DAW, so you record the room without a separate audio interface. Bluetooth MP3 playback handles the other direction, routed as an additional stereo source that mixes alongside every other channel.
Can I Build Separate Monitor Mixes?
Yes. AUX 1 and 2 are switchable pre-fader or post-fader, which is what you need for dedicated monitor sends that do not follow your front of house fader moves. AUX 3 and the AUX/FX send handle effects and additional feeds.
Inputs and Outputs
| Mono Inputs | 12 channels, combo jacks with inserts |
| Stereo Inputs | 2 channels |
| Aux Sends | 3 balanced XLR plus 1 AUX/FX, AUX 1-2 pre or post fader selectable |
| Group Outputs | 2 balanced group outputs |
| Bluetooth | Yes, for playback |
| Computer | USB Type-B sound card interface |
| Phantom Power | +48V per channel, individually switched |
Specifications
| Product Type | Analog Audio Mixer with DSP |
| Mono Inputs | 12 channels |
| Stereo Inputs | 2 channels |
| DSP Effects | 199 effects, 100 preset and 100 editable |
| Channel EQ | HF, MF with sweep, LF |
| Auxiliary Outputs | 3 AUX balanced XLR plus 1 AUX/FX, AUX 1-2 pre or post fader selectable |
| Group Outputs | 2 balanced group outputs |
| Phantom Power | +48V, individually switched per channel |
| Faders | 60 mm high precision |
| Digital Connectivity | Bluetooth, MP3 and audio playback |
| Computer Interface | USB Type-B sound card interface for direct DAW recording |
| MP3 EQ | 3-band, high, mid, low |
| Lighting | Built-in LED bar with individual switch |
| Built-in Amplifier | Yes, Class D. 350W x 2 RMS per dealer documentation, marketed by FEUR as 1400 W Class D |
| Power Supply | Switching supply, 110 to 240V |
| Approximate Size | 605 mm x 323 mm (23.8 in x 12.7 in) |
Certifications and Industry Recognition
| NAMM Member | Member of the National Association of Music Merchants, the global trade association for the music products industry. |
| USA Verified | Manufactured and quality checked under FEUR's USA verification standards. |
| CE Marking | Compliant with European Union safety, health and environmental protection directives. |
| RoHS Compliant | Free from restricted hazardous substances under the RoHS directive. |
| FCC Compliance | Compliant with applicable FCC regulations for wireless audio transmission. |
Why FEUR?
FEUR was founded in Germany by a team of engineers and sound specialists who set out to make professional audio equipment that performs at a high level and stays within reach of the people who actually use it every week. Where most of the industry aims either at high-end studio work or at the bottom of the market, FEUR builds for the working middle: independent artists, houses of worship, schools, mobile operators and installed systems that need gear to show up and work every week.
Frequently Asked Questions
Is this a genuine FEUR product?
Yes. Victory is a veteran owned dealer in Miami and units ship new in original packaging.
Does this mixer come with a warranty?
Yes. It carries the FEUR manufacturer warranty against defects in materials and workmanship. Keep your invoice and call us at 844-687-4208 if you ever need service.
Does it need a separate power amplifier?
No. The Class D amplifier is built in and drives passive speakers directly, which is the whole point of the model. Confirm your cabinet impedance with us at 844-687-4208 first.
Can I use it with a computer?
Yes. The USB Type-B sound card interface connects the mixer to a computer DAW for recording and playback without an extra interface. A 1.5 m USB cable ships in the box.
Can Bluetooth and microphones run at the same time?
Yes. Bluetooth MP3 playback is routed as an additional stereo source and mixes alongside all the microphone and line channels.
Will it fit in a rack?
This is a desktop and stage-top surface, not a rack mixer. Approximate footprint is 23.8 in x 12.7 in. Measure your cart or console slot before ordering.
