RME Digiface AVB is a 256-Channel 192 kHz USB Audio Interface. Connectivity covers RME USB 3.0, 1 x Phones Output, TotalMix FX, ARC USB, Word Clock I/O, Gigabit Ethernet (802.3 compliant).
Studio-grade conversion and RME driver stability in one box.
Overview
Digiface AVB - RME Audio Interfaces | Format Converters | Preamps | Network Audio & MADI Solutions
Developed by RME, Digiface AVB is a glance into the future of audio network technology. The device uses AVB, an open protocol developed by the IEEE, to transfer up to 256 channels of audio between PC and audio network. An additional headphone output allows high quality monitoring.
Take5 Music Production continues to rely on MADI technology, with the new MADIface XT II from RME being a highly anticipated addition. MADI, a trusted audio interface we've used for 20 years, remains integral to our operations.
At a Glance
| Type | Audio Interface |
| Description | 256-Channel 192 kHz USB Audio Interface |
| Series | Digiface |
| Connectivity | RME USB 3.0, 1 x Phones Output, TotalMix FX, ARC USB, Word Clock I/O |
| Supported sample rates | 44.1 kHz up to 192 kHz |
| Power supply | USB bus power |
| Dimensions (WxHxD) | 112 x 26 x 83 mm (4.41" x 1.02" x 3.27") |
| Availability | Sourced to order, call 844-687-4208 |
What Connections Does the Digiface AVB Have?
Digiface AVB carries the following connectivity, taken from RME's own specification for this model.
| RME USB 3.0 | Yes |
| Phones Output | 1 x |
| TotalMix FX | Yes |
| ARC USB | Yes |
| Word Clock I/O | Yes |
| Gigabit Ethernet (802.3 compliant) | Yes |
| DC-coupled Outputs (Phones) | Yes |
| Exploring new Ways to transport Audio | Yes |
| RME’s Digiface AVB | Yes |
Who Is the Digiface AVB For?
It is aimed at engineers, producers and integrators who need RME conversion and driver stability in this format. If you are matching it into an existing rig and want the channel counts and clocking confirmed before you order, call 844-687-4208 and we will check it against your setup.
Specifications
| Standard port LEDs | yellow connected, green data transmission |
| Max level | 5 Vss |
| Level with termination 75 Ohm | 4.0 Vss |
| Internal impedance | 10 Ohm |
| Dynamic range (DR) | 110 dB RMS unweighted, 113 dBA |
| Frequency response @ 44.1 kHz, -0.5 dB | 0 Hz - 20.8 kHz |
| Frequency response @ 96 kHz, -0.5 dB | 0 Hz - 45 kHz |
| Frequency response @ 192 kHz, -1 dB | 0 Hz - 89 kHz |
| THD @ -1 dBFS | - 96 dB, 0.0016 % |
| THD+N @ -1 dBFS | -95 dB, 0.0017 % |
| Channel separation | > 100 dB |
| Output | 6.3 mm TRS jack, unbalanced |
| Output impedance | 2 Ohm |
| Output level at 0 dBFS, 1 kOhm load | +9.5 dBu |
| Max power @ 0.1% THD | 50 mW |
| Clocks | Internal, AVB, Word |
| Supported sample rates | 44.1 kHz up to 192 kHz |
| Power supply | USB bus power |
| Typical power consumption | 1.5 Watts |
| Current at 5 V bus power operation | 300 mA |
| Max power consumption | 2 Watts (400 mA) |
| Dimensions (WxHxD) | 112 x 26 x 83 mm (4.41" x 1.02" x 3.27") |
Why RME?
RME designs and builds its interfaces and converters in Germany and is known for driver support that outlasts the hardware, with current releases for products sold more than a decade ago. TotalMix FX, the routing and monitoring engine shared across the line, runs on the device itself rather than the host computer, so monitoring stays stable regardless of what the computer is doing.
Frequently Asked Questions
Is this a genuine RME product?
Yes. Victory is a veteran owned dealer in Miami and units ship new in original packaging.
Is this covered by a warranty?
Yes. It carries the full RME manufacturer warranty, and we handle warranty claims for units purchased from us.
How quickly does this ship?
This item is sourced to order. Call 844-687-4208 and we will confirm current lead time before you buy.
Do you offer local pickup?
Yes. Free local pickup is available at our Miami location once the item arrives.
Which operating systems are supported?
RME publishes current drivers for Windows and macOS, and maintains them long after release. Check RME's download page for the release matching your operating system version.
Can you confirm compatibility with my existing system?
Yes. Call 844-687-4208 with your interface, converter or console model and we will confirm channel counts, clocking and cabling before you order.
