RME Digiface Ravenna is a 256-Channel 192 kHz USB Audio Interface. Connectivity covers RME USB 3.0, 1 x Phones Output, TotalMix FX, ARC USB, Word Clock I/O, 4 x Gigabit Ethernet (802.3 compliant).
Studio-grade conversion and RME driver stability in one box.
Overview
Digiface Ravenna | Portable RAVENNA via USB - RME Audio Interfaces | Format Converters | Preamps | Network Audio & MADI Solutions
The Digiface Ravenna is a lightweight, portable audio interface, based on the proven Digiface Dante equipped with a RAVENNA module developed by DirectOut and features with everything that RME is famous for: USB 3, MADI, TotalMix FX and outstanding options in both USB and stand-alone operation.
The combination of RME’s renowned drivers (Mac/Windows) and DirectOut’s RAVENNA implementation offer a reliable and flexible networked computer audio interface. Equipped with the latest TotalMix FX it can not only route, but also mix as many independent submixes as outputs are available. The included high quality phones output offers a quick listen to any audio channel, but can also be used as line output to provide an additional analog stereo mixdown.
At a Glance
| Type | Audio Interface |
| Description | 256-Channel 192 kHz USB Audio Interface |
| Series | Digiface |
| Connectivity | RME USB 3.0, 1 x Phones Output, TotalMix FX, ARC USB, Word Clock I/O |
| Sample Rates | 44.1, 48, 88.2, 96, 176.4, 192 kHz, +/-12.5 % |
| Availability | Sourced to order, call 844-687-4208 |
What Connections Does the Digiface Ravenna Have?
Digiface Ravenna carries the following connectivity, taken from RME's own specification for this model.
| RME USB 3.0 | Yes |
| Phones Output | 1 x |
| TotalMix FX | Yes |
| ARC USB | Yes |
| Word Clock I/O | Yes |
| Gigabit Ethernet (802.3 compliant) | 4 x |
| MADI I/O coaxial | 1 x |
Who Is the Digiface Ravenna For?
It is aimed at engineers, producers and integrators who need RME conversion and driver stability in this format. If you are matching it into an existing rig and want the channel counts and clocking confirmed before you order, call 844-687-4208 and we will check it against your setup.
Specifications
| Standard port LEDs | yellow connected, green data transmission |
| Modes | Switched and Redundancy according to ST 2022-7 |
| Clock sources | PTP, Internal |
| Sample Rates | 44.1, 48, 88.2, 96, 176.4, 192 kHz, +/-12.5 % |
| Routing | Channel-based routing matrix |
| Configuration | Browser GUI, globcon control, NMOS IS-04 / IS-05 |
| Standard | up to 64 channels 24 bit 48 kHz |
| S/MUX | up to 32 channels 24 bit 96 kHz |
| S/MUX4 | up to 16 channels 24 bit 192 kHz |
| Lock range | 25 kHz - 54 kHz |
| Cable length | up to 50 m |
| S/MUX / 96k Frame | up to 32 channels 24 bit 96 kHz |
| Dynamic range (DR) | 110 dB RMS unweighted, 113 dBA |
| Frequency response @ 44.1 kHz, -0.5 dB | 0 Hz - 20.8 kHz |
| Frequency response @ 96 kHz, -0.5 dB | 0 Hz - 45 kHz |
| Frequency response @ 192 kHz, -1 dB | 0 Hz - 89 kHz |
| THD @ -1 dBFS | - 96 dB, 0.0016 % |
| THD+N @ -1 dBFS | -95 dB, 0.0017 % |
| Channel separation | > 100 dB |
| Output | 6.3 mm TRS jack, unbalanced |
| Output impedance | 2 Ohm |
| Output level at 0 dBFS, 1 kOhm load | +9.5 dBu |
Why RME?
RME designs and builds its interfaces and converters in Germany and is known for driver support that outlasts the hardware, with current releases for products sold more than a decade ago. TotalMix FX, the routing and monitoring engine shared across the line, runs on the device itself rather than the host computer, so monitoring stays stable regardless of what the computer is doing.
Frequently Asked Questions
Is this a genuine RME product?
Yes. Victory is a veteran owned dealer in Miami and units ship new in original packaging.
Is this covered by a warranty?
Yes. It carries the full RME manufacturer warranty, and we handle warranty claims for units purchased from us.
How quickly does this ship?
This item is sourced to order. Call 844-687-4208 and we will confirm current lead time before you buy.
Do you offer local pickup?
Yes. Free local pickup is available at our Miami location once the item arrives.
Which operating systems are supported?
RME publishes current drivers for Windows and macOS, and maintains them long after release. Check RME's download page for the release matching your operating system version.
Can you confirm compatibility with my existing system?
Yes. Call 844-687-4208 with your interface, converter or console model and we will confirm channel counts, clocking and cabling before you order.
