RME Fireface UFX II is a 60-Channel 192kHz high-end USB Audio Interface now with SteadyClock FS. Connectivity covers 12 x Analog I/O, 4 x XLR/TRS Mic/Inst/Line, 2 x Phones Output, 1 x AES/EBU I/O, 2 x ADAT I/O, 1 x Word Clock I/O.
Studio-grade conversion and RME driver stability in one box.
Overview
Fireface UFX II - RME Audio Interfaces | Format Converters | Preamps | Network Audio & MADI Solutions
The unique Fireface UFX II is the premier solution to transfer analog and digital audio data directly to a computer from practically any source.
Numerous unique features like SteadyClock FS, improved AD/DA Conversion, DC-coupled analog outputs, well thought-out configuration dialogs, an industry-leading mixing engine and monitoring solution, professional DSP effects and class-leading analog circuits with latest digital converters put the Fireface UFX II at the very top of the range of computer-based audio interfaces.
At a Glance
| Type | Audio Interface |
| Description | 60-Channel 192kHz high-end USB Audio Interface now with SteadyClock FS |
| Series | Fireface |
| Connectivity | 12 x Analog I/O, 4 x XLR/TRS Mic/Inst/Line, 2 x Phones Output, 1 x AES/EBU I/O, 2 x ADAT I/O |
| Availability | Sourced to order, call 844-687-4208 |
What Connections Does the Fireface UFX II Have?
Fireface UFX II carries the following connectivity, taken from RME's own specification for this model.
| Analog I/O | 12 x |
| XLR/TRS Mic/Inst/Line | 4 x |
| Phones Output | 2 x |
| AES/EBU I/O | 1 x |
| ADAT I/O | 2 x |
| Word Clock I/O | 1 x |
| MIDI I/O | 2 x |
| RME USB 2.0 | 1 x |
Who Is the Fireface UFX II For?
It is aimed at engineers, producers and integrators who need RME conversion and driver stability in this format. If you are matching it into an existing rig and want the channel counts and clocking confirmed before you order, call 844-687-4208 and we will check it against your setup.
Specifications
| Input | 6.3 mm TRS, electronically balanced |
| Signal to Noise ratio (SNR) @ LoGain | 116 dB (AES17), 118 dBA |
| Signal to Noise ratio (SNR) @ +4 dBu | 115 dB (AES17), 117 dBA |
| Frequency response @ 44.1 kHz, -0.1 dB | 8.9 Hz - 20.4 kHz |
| Frequency response @ 96 kHz, -0.5 dB | 4.3 Hz - 45.2 kHz |
| Frequency response @ 192 kHz, -1 dB | 3 Hz - 89 kHz |
| Filter | Short Delay Sharp, 5 / 5 / 6 samples delay |
| THD @ -1 dBFS | < -120 dB, < 0.0001 % |
| THD+N @ -1 dBFS | < -110 dB, < 0.00032 % |
| Channel separation | > 110 dB |
| Maximum input level | +19 dBu |
| Input | 6.3 mm TRS jack, electronically balanced |
| Input impedance @ 1 kHz | 10 kOhm unbalanced, 10.6 kOhm balanced |
| Input level for 0 dBFS @ Lo Gain | +19 dBu |
| Input level for 0 dBFS @ +4 dBu | +13 dBu |
| Variable digital gain | 0 to +12 dB |
| Minimum level for 0 dBFS | +1 dBu, -1.2 dBV |
| Input | XLR, electronically balanced |
| Input impedance @ 1 kHz | 3.4 kOhm |
| Signal to Noise ratio (SNR) @ 0 dB Gain | 117 dB (AES17), 119.5 dBA |
| THD+N @ -1 dBFS, Gain 20 dB | < -110 dB, < 0.00032 % |
| Frequency response @ 44.1 kHz, -0.1 dB | 10.7 Hz - 20.3 kHz |
Why RME?
RME designs and builds its interfaces and converters in Germany and is known for driver support that outlasts the hardware, with current releases for products sold more than a decade ago. TotalMix FX, the routing and monitoring engine shared across the line, runs on the device itself rather than the host computer, so monitoring stays stable regardless of what the computer is doing.
Frequently Asked Questions
Is this a genuine RME product?
Yes. Victory is a veteran owned dealer in Miami and units ship new in original packaging.
Is this covered by a warranty?
Yes. It carries the full RME manufacturer warranty, and we handle warranty claims for units purchased from us.
How quickly does this ship?
This item is sourced to order. Call 844-687-4208 and we will confirm current lead time before you buy.
Do you offer local pickup?
Yes. Free local pickup is available at our Miami location once the item arrives.
Which operating systems are supported?
RME publishes current drivers for Windows and macOS, and maintains them long after release. Check RME's download page for the release matching your operating system version.
Can you confirm compatibility with my existing system?
Yes. Call 844-687-4208 with your interface, converter or console model and we will confirm channel counts, clocking and cabling before you order.
